| Type of control system | Fully automatic with CNC Panel |
| Crimping capacity of 2 wire hose | 1/4" to 2 1/2 inches |
| Crimping capacity of 4 wire hose | 1/4" to 2 inches 6 spiral hose |
| Power required | 3 phase 4 HP / Single phase 3 HP |
| Voltage | 440 V / 230 V |
| Opening at front side | 160 mm |
| Maximum inside opening without dies | 132 mm |
| Maximum opening with dies | Die diameter plus 33 mm |
| Opening at rear side | 150 mm |
| Capacity of oil tank | 32 litres |
| No of dies | 13 |
| Sizes of dies | 14, 16, 19, 22, 26, 30, 34, 39, 45, 51, 57, 63, 69 |
| Noise Level | < 70 db |
| Weight of the machine | 310 kgs |
| Dimension of the machine | 850 x 600 x 1260 mm |
| Dimension of export packing | 780 x 680 x 840 mm; 680 x 330 x 650 mm |
| Type of control system | Fully automatic with CNC Panel |
| Crimping capacity of 2 wire hose | 1/4" to 2 1/2 inches |
| Crimping capacity of 4 wire hose | 1/4" to 2 inches 6 spiral hose |
| Power required | 3 phase 4 HP / Single phase 3 HP |
| Voltage | 440 V / 230 V |
| Opening at front side | 160 mm |
| Maximum inside opening without dies | 132 mm |
| Maximum opening with dies | Die diameter plus 33 mm |
| Opening at rear side | 150 mm |
| Capacity of oil tank | 32 litres |
| No of dies | 13 |
| Sizes of dies | 14, 16, 19, 22, 26, 30, 34, 39, 45, 51, 57, 63, 69 |
| Noise Level | < 70 db |
| Weight of the machine | 310 kgs |
| Dimension of the machine | 850 x 600 x 1260 mm |
| Dimension of export packing | 780 x 680 x 840 mm; 680 x 330 x 650 mm |
Key Features & Highlights
-
Advanced PLC-based CNC control system with digital touchscreen interface
-
Slim crimping head with wide opening for faster hose loading
-
High crimping force suitable for demanding industrial applications
-
Quick-change die system with integrated die holder and storage stand
-
Precise digital setting for crimp diameter and repeatability
-
Premium-grade hydraulic pumps and valves from globally trusted manufacturers
-
Covered foot pedal with dust-resistant seals for workshop safety and durability
-
Hydraulic hose manufacturing units with batch production requirements
-
OEM and industrial assembly lines needing repeatable crimp accuracy
-
Heavy equipment and earthmoving hydraulic hose assembly
-
High-pressure hose applications where tolerance control is critical
-
Workshops upgrading from manual or semi-automatic crimping systems
-
1-year warranty covering manufacturing defects
-
Backed by NPower’s dedicated after-sales support network
-
Prompt technical assistance and guidance available
-
Spare parts availability to ensure long-term reliability
Applications & Typical Workshop Use Cases
- Hydraulic hose assembly units
- Industrial maintenance shops
- On-site hose repair & service
- Construction equipment maintenance
- Agricultural machinery service
- Fabrication workshops preparing hoses for crimping
Hose skiving machines improve quality, speed up assembly prep, and reduce the risk of hose failure after crimping.
Warranty, Service & Support
Every NPOWER Hand-Operated Hose Skiving Machine comes with:
- 1-Year Standard Warranty
- Dedicated after-sales support
- Spare parts and accessory availability
- Technical guidance for operation and maintenance
Ensures long-term reliability even in continuous workshop environments.
- Advanced PLC-based CNC control system with digital touchscreen interface
- Slim crimping head with wide opening for faster hose loading
- High crimping force suitable for demanding industrial applications
- Quick-change die system with integrated die holder and storage stand
- Precise digital setting for crimp diameter and repeatability
- Premium-grade hydraulic pumps and valves from globally trusted manufacturers
- Covered foot pedal with dust-resistant seals for workshop safety and durability
- Hydraulic hose manufacturing units with batch production requirements
- OEM and industrial assembly lines needing repeatable crimp accuracy
- Heavy equipment and earthmoving hydraulic hose assembly
- High-pressure hose applications where tolerance control is critical
- Workshops upgrading from manual or semi-automatic crimping systems
- 1-year warranty covering manufacturing defects
- Backed by NPower’s dedicated after-sales support network
- Prompt technical assistance and guidance available
- Spare parts availability to ensure long-term reliability
- Hydraulic hose assembly for industrial machinery
- Mobile workshop and field repair operations
- Automotive and agricultural equipment maintenance
- OEM production lines requiring consistent crimp quality
All N Power machines come with a 12-month warranty covering manufacturing defects. Warranty does not cover damage caused by misuse, unauthorized modification, or normal wear and tear. Contact PVN Industries for warranty claims and service support.
