| Voltage | 24 V DC |
| Type of control system | Semi-Automatic |
| Crimping capacity of 2 wire hose | $1/4"$ to 2 inches (6 mm - 50 mm) |
| Crimping capacity of 4 wire hose | $1/4"$ to 2 inches (6 mm - 50 mm) |
| Power required | 4.5 HP |
| Opening at front side | 160 mm |
| Maximum inside opening without dies | 132 mm |
| Maximum opening with dies | Dia diameter plus 33 mm |
| Opening at rear side | 150 mm |
| Capacity of oil tank | 9 litres |
| No of dies | 13 |
| Sizes of dies | 14, 16, 19, 22, 26, 30, 34, 39, 45, 51, 57, 63, 69 |
| Noise Level | $< 75$ db |
| Dimension of the machine | $570 \times 520 \times 530$ mm |
| Dimension of export packing | $780 \times 680 \times 840$ mm |
| Voltage | 24 V DC |
| Type of control system | Semi-Automatic |
| Crimping capacity of 2 wire hose | $1/4"$ to 2 inches (6 mm - 50 mm) |
| Crimping capacity of 4 wire hose | $1/4"$ to 2 inches (6 mm - 50 mm) |
| Power required | 4.5 HP |
| Opening at front side | 160 mm |
| Maximum inside opening without dies | 132 mm |
| Maximum opening with dies | Dia diameter plus 33 mm |
| Opening at rear side | 150 mm |
| Capacity of oil tank | 9 litres |
| No of dies | 13 |
| Sizes of dies | 14, 16, 19, 22, 26, 30, 34, 39, 45, 51, 57, 63, 69 |
| Noise Level | $< 75$ db |
| Dimension of the machine | $570 \times 520 \times 530$ mm |
| Dimension of export packing | $780 \times 680 \times 840$ mm |
Key Features & Highlights
-
DC motor–driven hydraulic system for mobile and off-grid operation
-
High crimping force suitable for medium to large hydraulic hoses
-
Stable pressure control for uniform and repeatable crimps
-
Quick-release die system for faster job changeovers
-
Compact, rugged structure ideal for service trucks and field units
-
Industrial-grade pumps and valves for long service life
-
Designed to perform reliably in harsh outdoor environments
-
Mobile hydraulic hose repair vans
-
On-site maintenance for construction and mining equipment
-
Emergency hose replacement in remote locations
-
Agricultural machinery field servicing
-
Industrial breakdown maintenance teams
-
Service operations where AC power is unavailable or unreliable
-
The X52 DC is backed by a 1-year standard warranty covering manufacturing defects
-
NPower provides dedicated after-sales support, technical assistance, and easy access to service parts to ensure uninterrupted operation throughout the machine’s service life
Applications & Typical Workshop Use Cases
- Hydraulic hose assembly units
- Industrial maintenance shops
- On-site hose repair & service
- Construction equipment maintenance
- Agricultural machinery service
- Fabrication workshops preparing hoses for crimping
Hose skiving machines improve quality, speed up assembly prep, and reduce the risk of hose failure after crimping.
Warranty, Service & Support
Every NPOWER Hand-Operated Hose Skiving Machine comes with:
- 1-Year Standard Warranty
- Dedicated after-sales support
- Spare parts and accessory availability
- Technical guidance for operation and maintenance
Ensures long-term reliability even in continuous workshop environments.
- DC motor–driven hydraulic system for mobile and off-grid operation
- High crimping force suitable for medium to large hydraulic hoses
- Stable pressure control for uniform and repeatable crimps
- Quick-release die system for faster job changeovers
- Compact, rugged structure ideal for service trucks and field units
- Industrial-grade pumps and valves for long service life
- Designed to perform reliably in harsh outdoor environments
- Mobile hydraulic hose repair vans
- On-site maintenance for construction and mining equipment
- Emergency hose replacement in remote locations
- Agricultural machinery field servicing
- Industrial breakdown maintenance teams
- Service operations where AC power is unavailable or unreliable
- The X52 DC is backed by a 1-year standard warranty covering manufacturing defects
- NPower provides dedicated after-sales support, technical assistance, and easy access to service parts to ensure uninterrupted operation throughout the machine’s service life
- Hydraulic hose assembly for industrial machinery
- Mobile workshop and field repair operations
- Automotive and agricultural equipment maintenance
- OEM production lines requiring consistent crimp quality
All N Power machines come with a 12-month warranty covering manufacturing defects. Warranty does not cover damage caused by misuse, unauthorized modification, or normal wear and tear. Contact PVN Industries for warranty claims and service support.
